SUPLY AND INSTALLATION OF COMPLETE Ø 600 mm PE WASTE WATER AND STORM WATER INSPECTION CHAMBERS
Price of one inspection chamber including; procurement of Ø600 mm diameter, base channeled complete inspection chamber from TSE approved manufacturer and as per the technical specification, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the manhole is to be placed, transportation to the excavation hole, proper base leveling or base improvement with a base foundation concrete or placement of prefabricated base plate concrete slab and lowering chamber into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level cutting the upper part; all kinds of material, labor, equipment, apparatus and transportation costs for manufacturing reinforced concrete rings to place cast iron covers on top of, Contractor profits and general expenses. This inspection chamber will be used with DN 200 diameter lines with or without chutes and inspection chamber depth will be taken as distance between pipe flow level to cover top level.


Units: Is number of complete inspection chambers erected in situ as per the design project.
Unit price for TYPE 1 H less than 0,50 mt
Unit price for TYPE 2 H=0,51-0,75 mt
Unit price for TYPE 3 H=0,76-1,00 mt
Unit price for TYPE 4 H=1,01-1,25 mt
Unit price for TYPE 5 H=1,26-1,50 mt
Unit price for TYPE 6 H=1,51-1,75 mt
Unit price for TYPE 7 H=1,76-2,00 mt

SUPLY AND INSTALLATION OF COMPLETE Ø 800 mm PE WASTE WATER AND STORM WATER MANHOLES
Price of one manhole including; procurement of Ø800 mm diameter, base channeled complete manhole from TSE approved manufacturer and as per the technical specification, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the manhole is to be placed, transportation to the excavation hole, proper base leveling or base improvement with a base foundation concrete or placement of prefabricated base plate concrete slab and lowering chamber into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level cutting the PE conical upper part; all kinds of material, labor, equipment, apparatus and transportation costs for manufacturing reinforced concrete rings to place cast iron covers on top of, Contractor profits and general expenses. This manhole will be used with DN 200, DN 300, DN 400 diameter lines with or without chutes and manhole depth will be taken as distance between pipe flow level to cover top level.


Units: Is number of complete manholes erected in situ as per the design project.
Unit price for TYPE 1 H less than 1,50 mt
Unit price for TYPE 2 H=1,51-1,75 mt
Unit price for TYPE 3 H=1,76-2,00 mt
Unit price for TYPE 4 H=2,01-2,25 mt
Unit price for TYPE 5 H=2,26-2,50 mt
Unit price for TYPE 6 H=2,51-2,75 mt
Unit price for TYPE 7 H=2,76-3,00 mt
Unit price for TYPE 8 H=3,01-3,25 mt
Unit price for TYPE 9 H=3,26-3,50 mt
Unit price for TYPE 10 H=3,51-3,75 mt
Unit price for TYPE 11 H=3,76-4,00 mt


SUPLY AND INSTALLATION OF COMPLETE Ø 1000 mm PE WASTE WATER AND STORM WATER MANHOLES
Price of one manhole including; procurement of Ø1000 mm diameter, base channeled complete manhole from TSE approved manufacturer and as per the technical specification, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the manhole is to be placed, transportation to the excavation hole, proper base leveling or base improvement with a base foundation concrete or placement of prefabricated base plate concrete slab and lowering chamber into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level cutting the PE conical upper part; all kinds of material, labor, equipment, apparatus and transportation costs for manufacturing reinforced concrete rings to place cast iron covers on top of, Contractor profits and general expenses. This manhole will be used with DN 200, DN 300, DN 400, DN 500, DN 600 diameter lines with or without chutes and manhole depth will be taken as distance between pipe flow level to cover top level.

Units: Is number of complete manholes erected in situ as per the design project.
Unit price for TYPE 1 H less than 1,50 mt
Unit price for TYPE 2 H=1,51-1,75 mt
Unit price for TYPE 3 H=1,76-2,00 mt
Unit price for TYPE 4 H=2,01-2,25 mt
Unit price for TYPE 5 H=2,26-2,50 mt
Unit price for TYPE 6 H=2,51-2,75 mt
Unit price for TYPE 7 H=2,76-3,00 mt
Unit price for TYPE 8 H=3,01-3,25 mt
Unit price for TYPE 9 H=3,26-3,50 mt
Unit price for TYPE 10 H=3,51-3,75 mt
Unit price for TYPE 11 H=3,76-4,00 mt
Unit price for TYPE 12 H=4,01-4,25 mt
Unit price for TYPE 13 H=4,26-4,50 mt
Unit price for TYPE 14 H=4,51-4,75 mt
Unit price for TYPE 15 H=4,76-5,00 mt
Unit price for TYPE 16 H=5,01-5,25 mt
Unit price for TYPE 17 H=5,26-5,50 mt
Unit price for TYPE 18 H=5,51-5,75 mt
Unit price for TYPE 19 H=5,76-6,00 mt



SUPLY AND INSTALLATION OF COMPLETE Ø 1250 mm PE WASTE WATER AND STORM WATER MANHOLES
Price of one manhole including; procurement of Ø1250 mm diameter, base channeled complete manhole from TSE approved manufacturer and as per the technical specification, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the manhole is to be placed, transportation to the excavation hole, proper base leveling or base improvement with a base foundation concrete or placement of prefabricated base plate concrete slab and lowering chamber into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level cutting the PE conical upper part; all kinds of material, labor, equipment, apparatus and transportation costs for manufacturing reinforced concrete rings to place cast iron covers on top of, Contractor profits and general expenses. This manhole will be used with DN 200 – DN 800 diameter lines with or without chutes and manhole depth will be taken as distance between pipe flow level to cover top level.




Units: Is number of complete manholes erected in situ as per the design project.
Unit price for TYPE 1 H less than 1,75 mt
Unit price for TYPE 2 H=1,76-2,00 mt
Unit price for TYPE 3 H=2,01-2,25 mt
Unit price for TYPE 4 H=2,26-2,50 mt
Unit price for TYPE 5 H=2,51-2,75 mt
Unit price for TYPE 6 H=2,76-3,00 mt
Unit price for TYPE 7 H=3,01-3,25 mt
Unit price for TYPE 8 H=3,26-3,50 mt
Unit price for TYPE 9 H=3,51-3,75 mt
Unit price for TYPE 10 H=3,76-4,00 mt
Unit price for TYPE 11 H=4,01-4,25 mt
Unit price for TYPE 12 H=4,26-4,50 mt
Unit price for TYPE 13 H=4,51-4,75 mt
Unit price for TYPE 14 H=4,76-5,00 mt
Unit price for TYPE 15 H=5,01-5,25 mt
Unit price for TYPE 16 H=5,26-5,50 mt
Unit price for TYPE 17 H=5,51-5,75 mt
Unit price for TYPE 18 H=5,76-6,00 mt

SUPLY AND INSTALLATION OF COMPLETE Ø 800 mm PE WASTE WATER AND STORM WATER PARCEL CHAMBERS
Price of one parcel chamber including; procurement of Ø800 mm diameter, complete parcel chamber including PE cover from TSE approved manufacturer, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the parcel chamber is to be placed, transportation to the excavation hole, proper base leveling or base improvement, lowering into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level all kinds of material, labor, equipment, apparatus and transportation costs for support concrete as may be necesssary, Contractor profits and general expenses.


Units: Is number of complete parcel chambers erected in situ or installed in place as per the design project.
Unit price for TYPE 1 H=1,50 mt

SUPLY AND INSTALLATION OF COMPLETE Ø 1000 mm PE WASTE WATER AND STORM WATER PARCEL CHAMBERS
Price of one parcel chamber including; procurement of Ø1000 mm diameter, complete parcel chamber including PE cover from TSE approved manufacturer, material PE, steps PE, PE base - PE risers – PE upper part connected with EPDM gaskets or PE welding technique for desired height, excavation of the hole the parcel chamber is to be placed, transportation to the excavation hole, proper base leveling or base improvement, lowering into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level all kinds of material, labor, equipment, apparatus and transportation costs for support concrete as may be necesssary, Contractor profits and general expenses.

Units: Is number of complete parcel chambers erected in situ or installed in place as per the design project.
Unit price for TYPE 1 H=2,00 mt

SUPLY AND INSTALLATION OF COMPLETE Ø 400 mm PE STORM WATER GULLY
Price of one gully including; procurement of Ø400 mm diameter, complete gully from TSE approved manufacturer, material PE, excavation of the hole the gully is to be placed, transportation to the excavation hole, proper base leveling or base improvement, lowering into the hole, placement as per the design project, proper backfill in steps, depending on the final ground level all kinds of material, labor, equipment, apparatus and transportation costs for support concrete as may be necesssary, Contractor profits and general expenses.
Units: Is number of complete gullies erected in situ or installed in place as per the design project.
Unit price for TYPE 1 H=0,80 mt
